(2026). Force-Velocity Test (F-V Profile) — Protocol, Norms and Application. Sporeus. Retrieved, September 25, 2026. https://sporeus.com/en/egzersiz-testleri-en/force-velocity-test-fv-profile/
Measures: Kuvvet-hız profili, teorik maksimal kuvvet (F0), teorik maksimal hız (V0)
Table of Contents
Difficulty: Zor | Category: Anaerobik
Protocol
The Force-Velocity (F-V) Profile Test, developed by Jean-Benoit Morin and Pierre Samozino, maps an athlete’s neuromuscular capacity on the force-velocity plane. In the field version, multiple weighted and unweighted sprint measurements are used.
Preparation: A flat 40–60m surface, GPS, or radar gun is required for the test. Alternatively, squat jump variations on a force platform can be used. The participant warms up comprehensively for 15–20 minutes.
Protocol: The participant performs maximal sprints under different conditions:
1. Body weight sprint (unloaded)
2. Sprints with additional weight (loaded vest, sled towing, etc.) at 3–5 different loads
Mean acceleration and power are calculated for each condition. In the sled-towing protocol, weights are set at 20%, 40%, 60%, 80% of body weight.
Data Recording: Mean velocity, force, and power values are recorded for each sprint. The F-V line is drawn by linear regression of these points at different loads.
Calculation:
– F0 (theoretical maximum force, x-intercept) = axis where maximum force production occurs
– V0 (theoretical maximum velocity, y-intercept) = maximum velocity capacity
– Pmax = F0 × V0 / 4 (maximum power)
– FV imbalance = identifies the deficient component in profile analysis
Post-Test: The F-V profile is drawn and the athlete’s strong/weak component is identified. A force- or velocity-focused training program is recommended accordingly.
Formula
Pmax = F0 × V0 / 4; FV imbalance = (actual slope - optimal slope) / optimal slope × 100
Equipment Required
force platform veya sprint fotosel sistemi, GPS tracker veya radar tabancası
Normative Values (Age: Elite sprinterlər)
| Classification | Male | Female |
|---|---|---|
| Excellent | Pmax >30 W/kg; FV dengesizliği <%10 | Pmax >25 W/kg |
| Good | Pmax 24-30 W/kg | Pmax 19-25 W/kg |
| Average | Pmax 18-24 W/kg | Pmax 13-19 W/kg |
| Below Average | Pmax 12-18 W/kg | Pmax 8-13 W/kg |
| Poor | Pmax <12 W/kg | Pmax <8 W/kg |
Practical Applications
F-V profile analysis determines which component — force or velocity — is limiting sprint performance and forms the basis for individualized power training design.
Limitations
Requires a reliable radar gun or loaded sled system. Profile calculation requires software; manual calculation is difficult.
Related Tests: 40m Sprint Test, Wingate Test, Margaria-Kalamen Test
Sources: Morin JB & Samozino P, 2016, Int J Sports Physiol Perform; Samozino P et al., 2012, Med Sci Sports Exerc
